Why Nissan designers didn’t put a tablet display in the Ariya Concept

When digital graphic displays were available for use in cars, they were inserted in the dashboard, usually in the middle section. Before long, interior designers began to bring the display ‘out’, giving it the form of a tablet like an iPad slotted onto the dashboard. Perhaps this made installation easier and users would also have appreciated the familiar tablet shape.

However, Nissan designers who work on next-generation vehicles consider other aspects as they attempt to balance design, technology and utility. For the Ariya Concept, they chose a different path when developing the display.

This prioritized design and vision over the latest trends. Instead of a tablet, the all-electric crossover has a curved, two-screen display reminiscent of a wave. It adds to the sense of a ‘horizon’ throughout the car, from elements in the door all the way to the rear of the cabin.

The layout reflects Nissan’s new ‘Timeless Japanese Futurism’ design language, also expressed in the Ariya Concept’s unique frontal ‘shield’. But the horizontal design wasn’t chosen for its good looks alone. In addition to conveying information better for the human eye, the layout does so from a safer location — in the line of sight, closer to the road.

By matching the cabin’s horizon aesthetic, it becomes a seamless part of the dashboard. Nissan’s design team calls this engawa – the undefined space between where you are, and where you are going.

“The human eye naturally looks from side to side when driving,” explained Tomomichi Uekuri, Senior Manager of the engineering team involved in HMI (Human-Machine Interface). “People can see and absorb more information if it’s laid out horizontally. Peripheral vision works this way as well.”

The Ariya Concept’s display keeps driving information in an instrument cluster location similar to that of a traditional car, while displaying entertainment information, comfort controls and system status in the centre screen. Both are wrapped together in a sleek panel that flows seamlessly between driver and passenger.

Even though there are two screens, information can move or be swiped between them to create the feeling of a single display. For example, if you want your route directions and map in front of the steering wheel, they can appear there. They can also move to the centre, or disappear when no longer needed.

“The display’s wave construction is innovative and utilizes an ergonomic layout for both the meter display and the centre display, not only for visibility, but also allows the driver to easily reach the touch screen,” Uekuri said.

It took the design team many tries to arrive at the innovative display. The team built similar displays into a large black ‘box’ that they affectionately named ‘the Monolith’, a nod to the movie ‘2001: A Space Odyssey’. They chipped away, figuratively speaking, at the housing until it became what’s seen in the final concept car.

As a result, the sleek, seamless display looks like a natural, integrated part of the interior design – not a slab out of time and place.

Nissan Ariya Concept unveiled at Tokyo Motor Show 2019 (w/VIDEO)

Goodyear reCharge tyre creates its own treads when needed (w/VIDEO)

Ever since the pneumatic tyre was invented, motorists have had to live with the possibility of the air inside leaking out due to being punctured by a nail or damage from hitting a pothole. Loss of air pressure, which is what keeps the tyre in its hard shape to roll along, means the tyre cannot be used and has to be replaced. Not something you want when you are on the way to a meeting or a holiday resort.

Various solutions have been developed over the years which try to keep the tyre usable even when the air is gone. Run-flat tyres are capable of continuing even when deflated, though at limited speeds and for a limited distance. Obviously, they need to be replaced or repaired as soon as possible.

More specialised tyres for off-road use have flexible foam inside which can maintain the tyre shape even when air has leaked out.

Regenerating the tread
Now Goodyear is taking another approach with a prototype tyre it calls recharge. This is reloadable and has a tread compound that can be recharged with individual capsules, radically simplifying the process of replacing your tyres.

Filled with a customized liquid compound, these capsules allow the tread to regenerate and the tyre to adapt over time to climatic circumstances, road conditions, or simply how you want to travel. Thanks to artificial intelligence, a driver profile would be created around which the liquid compound would be customized, generating a compound blend tailored to each individual.

The compound itself would be made from a biological material and would be reinforced with fibres inspired by one of the toughest natural materials in the world – spider silk. This would make it both extremely durable and 100% biodegradable.

No maintenance needed
In addition to radically simplifying the process of replacing tyres using the rechargeable capsules, the tread would be supported by a lightweight, non-pneumatic frame and tall-and-narrow shape. This is a thin, robust low-maintenance construction that would eliminate the need for pressure maintenance or downtime related to punctures.

“Goodyear wants the tyre to be an even more powerful contributor to answering consumers’ specific mobility needs,” said Mike Rytokoski, Vice-President and Chief Marketing Officer, Goodyear Europe, “It was with that ambition that we set out to create a concept tyre primed for the future of personalized and convenient electric mobility.”

Recharge is just a concept for now although it could become one of the features of tyres of the future. Only thing is, if the tread can be regenerated, then the tyres doesn’t need to be replaced. That’s good for the environment but is it going to be good for company business?

Goodyear Eagle F1 range in Malaysia widens with more choices

BMW iNEXT undergoes extreme testing conditions in Africa

On its way to being ready for production, the BMW iNEXT is completing additional vehicle testing under particularly demanding conditions. Intensive test runs in the freezing cold at the polar circle are now being followed by a contrasting program in the Kalahari in southern Africa.

In addition to extreme heat and solar radiation, permanent dust formation and off-road terrain with its sand, pebble and gravel tracks pose exceptional challenges for the BMW Group’s technology flagship.

The test drives through the desert and savanna regions in the northwest corner of South Africa are in temperatures that would drain any mobilephone battery in no time at all. This puts a severe test on the integrated cooling concept for the high-voltage battery, the electric motor and the vehicle electronics.

During extensive heat tests, the car is repeatedly exposed to the heat of the sun for hours and later cooled down. In this way, the developers test not only the operability of the electrical systems but also the temperature stability of the materials used in the interior.

Moreover, the interior air conditioning, which operates by means of thermal pump technology, its control system and all further components of the electronics, are subjected to the extreme conditions of the desert climate.

Every part and system stress-tested
In this literally hot phase of the product development process, not only do the drive and suspension components of the iNEXT – a car designed for all-electric mobility – have to provide proof of their functional safety, durability and reliability, but also the car’s bodywork, interior, driver assistance systems and digitalisation technology.

The ‘hot climate’ tests are an integral part of a both extensive and varied development and test program. Prototypes are subjected virtually in time-lapse to the stress of an entire car’s service life.

Real-world conditions
Like every new BMW model, the prototypes are also driven at the proving ground at Miramas in southern France, the Nurburgring Nordschleife and other racetracks as well as the Winter Centre in Sweden.

With high-speed operation, stop/go traffic, extreme temperatures below and above zero, testing on ice and snow as well as desert sand and gravel, the pre-production cars are put through a concentrated form all of the challenges an automobile may face in everyday traffic over a period of many years.

Fifth generation BMW eDrive technology
Featuring fifth-generation BMW eDrive technology, the iNEXT is said to set new benchmarks in sportiness, efficiency and range in a battery-powered automobile. The car’s suspension control and driver assistance systems pave the way for a further step towards autonomous driving. Current innovations in the field of operation and digitalisation also underscore the future-oriented character of the iNEXT.

Production of the iNEXT will commence at the BMW Dingolfing plant in 2021. Designed as a modern Sports Activity Vehicle, the new model combines the latest innovations defined by the BMW Group in its corporate NUMBER ONE > NEXT strategy for the future fields D-ACES (Design, Autonomous, Connected, Electrified und Services).

5th generation BMW eDrive technology to debut in iX3 next year

Max Verstappen and Alex Albon test-drive the Aston Martin Valkyrie hypercar

Aston Martin has unleashed the power of three of its Valkyrie models, with Max Verstappen and Alex Albon – the Aston Martin Red Bull Racing drivers – getting their first taste of the revolutionary hypercar.

While each Formula 1 driver drove the first verification prototype (VP) that made its public debut at last year’s British Grand Prix (Aston Martin Valkyrie VP1), both VP2 and VP3 were taken round by the company’s high-performance test driver Chris Goodwin and Aston Martin Racing WEC drivers Darren Turner and Alex Lynn.

Each verification prototype, of which there will be 8 built in total, is subjected to a variety of intense testing programmes designed to develop and validate specific attributes that contribute to achieving the performance of the world’s fastest ever road-going hypercar. These programmes are focussed on supporting first customer deliveries starting in the second half of this year.

“This event has been an incredibly important step in Aston Martin Valkyrie’s story. To have three cars now running will see the rate of physical development for this exceptional hypercar increase exponentially. Both Max and Alex were really positive of the direction that we’re currently taking and could see that the ingredients for an exceptionally high-performing car are already there ready to be untapped. To have that second opinion and validation doesn’t mean the hard work is done already, but this is a great step on our journey,” said Goodwin.

8-time Grand Prix winner Verstappen came away elated by his first laps in the Valkyrie. He said: “I was here at Silverstone to watch the first runs of the Aston Martin Valkyrie at the British Grand Prix last year but of course it’s always better to be behind the wheel yourself! To be one of the first guys to drive an insane car like this was really exciting… it was amazing to get a first taste of it.”

“Of course, it’s still in the development phase but you can already feel the pace, which compared to a normal car is… pretty different! The Aston Martin Valkyrie and its levels of downforce are incredible, and it looks super aggressive. It was a lot of fun out there,” he added.

Albon was equally pleased with his drive. “It was incredibly exciting to have this opportunity to drive the Aston Martin Valkyrie and the first thing that struck me was the visual aspect – it looks awesome! It also really feels like a racing car,” said the Thai driver.

“Obviously there’s still some development to do, but already it feels very good, especially the balance between the corners. It’s light; it feels sharp. Sure, compared to an F1 car, you’re missing the outright downforce, but you still feel the g-forces in the corners and it definitely reacts closer to an F1 car than a normal roadcar. It’s pretty special. I just need to get my hands on one!” he said.

Aston Martin Valkyrie will compete in Le Mans 2021

CUPRA uses 3D printing for new TCR racing car’s parts (w/VIDEO)

At first glance, it looks like a normal mirror, but it isn’t. It is a 3D-printed part, a technology that CUPRA has begun to implement in the development of the new Leon Competition racing car in collaboration with HP. Greater agility, efficiency and flexibility are the benefits of a system that is set to revolutionise car development.

“For the new CUPRA Leon Competition, we modelled the steering wheel’s centre control module, the bonnet air vents, door mirrors and the brake and water-cooling inlets,” explained Xavi Serra, the Head of technical development at CUPRA Racing. “These parts were produced using HP’s industrial-grade Jet Fusion 5200 3D printing solution and included in the demanding development tests put to the new racing model.”

More efficiency, greater speed
The main goal with this technology, which offers multiple benefits, is to have a lot of parts in a short time. Engineers can quickly test a wide variety of designs and furthermore, since vehicle development is now done in parallel, this technology enables quicker response to any changes in the design process.

“The work with CUPRA demonstrates the power of 3D printing and digital manufacturing – changing the way the world designs and manufactures,” said Virginia Palacios, Head of Systems Product Management, 3D Printing & Digital Manufacturing, HP Inc.

Wind-tested 3D parts
In TCR competition, the door mirror is a part which, according to the rules, must have the same shape as the production car. But the CUPRA engineers went one step further. “We wanted to add an additional function, which is to cool the driver. We therefore had to design an air intake in the maximum pressure zone to achieve this effect,” said Xavi.

The place where these materials are tested is the wind tunnel, where the 3D-printed parts are verified in exactly the same way as the rest. “The bigger the variety of parts we can test in this facility, the better. It enables us to make much faster progress,” he added.

2020 CUPRA Competition — *The new Leon Competition with its 3D printed parts was tested to the limit on the Portimao track in Portugal.*

As it is a racing car, the final phase of development can only be carried out in one place: the circuit. “The results were excellent, and some were even surprising, because we were looking to push the material to its limits,” the CUPRA engineer reported.

Making complex ideas a reality – fast
“3D printing is going to signal a turning point in the automotive industry by accelerating lead times and HP 3D technology is helping designers create parts that could not be produced with other technologies,” said Palacios, predicting that the technology will continue to be key in countless fields to make the most complex ideas a reality.

Watch: Onboard a race-spec Seat Cupra around Sepang Circuit!

Modernism-inspired camouflage used to disguise new SEAT model

The origin of the camouflage comes from a military tactic used on ships during World War I, known as the ‘Dazzle Camouflage’. It consisted of painting ships with black and white geometric patterns to blur their shapes and confuse the enemy. “The story goes that the artists who designed these camouflage patterns drew inspiration from Cubist paintings,” explained Edgar Aneas, an expert in vehicle camouflage.

Since the 1980s, carmakers have also used the same principle to camouflage their prototypes, especially when the vehicles need to be driven on public roads. Initially, the camouflage was simple – just black film taped onto the vehicle to conceal special styling elements. Sometimes, extra panels might be added to alter the shape and mislead competitors as to the actual design of the new model.

Over time, there was a need to make the camouflage more effective because computer software was becoming sophisticated and the design under the simple camouflage could be made more visible. This led to the patchy type of camouflage, not unlike that used for military clothing to reduce visibility of a soldier in the jungle or desert. Each brand uses its own camouflage and some even patent the design.

Inspired by Modernism and Barcelona
SEAT, the Spanish carmaker in the Volkswagen Group, has been using a unique camouflage for its all-new Leon model which will have its global premiere today. Official and unofficial pictures have shown the car wrapped in a broken tile vinyl inspired by Modernism and the city of Barcelona, the home of SEAT.

“The new SEAT Leon has a lot of personality and is very difficult to camouflage because it’s a sculpture on wheels that expresses SEAT’s emotional nature. The Leon was born here and because of the special relationship we have with Barcelona, we looked to the city for inspiration,” explained Jordi Font, head of SEAT’s Colour & Trim Development.

Developing a new design – the challenge
“This is the first time we didn’t use conventional camouflage. It was a challenge, because the main goal is to distort the shapes of the car. We worked on several versions to blur the lines but send a clear message – that we are Barcelona, that we are Mediterranean, and that we are colourful. We want to give meaning to our sculpture,” he said.

Not only does the camouflage have an aesthetic function but it must also withstand extreme weather and driving conditions. The material used is a special cast vinyl that resists these conditions.

“The cars are camouflaged so that they can be tested in different weather situations, sub-zero temperatures, long exposure to the elements, rain and desert heat. This vinyl is made with a very durable material and has special characteristics that prevent it from peeling off or deteriorating,” noted Aneas, the camouflage expert.

McLaren Hyper-GT prototype reaches 403 km/h at Kennedy Space Centre

The dynamic development programme for the fastest and most technically advanced McLaren ever ended with McLaren chief test driver, Kenny Brack, taking the new Speedtail up to its maximum speed of 403 km/h at the Kennedy Space Centre in Florida, USA.

McLaren Speedtail Hypercar — *The final high-speed tests were done on the runway that the space shuttles landed on.*

The final high-speed tests in the ground-breaking hypercar’s extensive engineering validation process saw Speedtail prototype designated ‘XP2’ reach its maximum speed more than 30 times on the space shuttle landing runway. The exercise concluded a programme of high-speed running carried out at multiple test facilities worldwide, including Idiada in Spain and Papenburg in Germany.

“It’s fitting that the Speedtail’s high-speed test programme concluded with multiple maximum-speed runs at a location strongly associated with pushing the boundaries of extreme performance and engineering excellence,” said McLaren Automotive CEO, Mike Flewitt. “The Speedtail is a truly extraordinary car that epitomises McLaren’s pioneering spirit and perfectly illustrates our determination to continue to set new benchmarks for supercar and hypercar performance.”

Blending sleek and seamless beauty with pioneering technologies and truly remarkable performance, the Speedtail sits at the pinnacle of the McLaren Ultimate Series. At almost 5.2 metres long, the carbonfibre-bodied 3-seat Hyper GT is the most aerodynamically drag-efficient McLaren ever and a showcase for the brand’s expertise in lightweight engineering.

1,070 ps, 1,150 Nm, 0 – 300 km/h in less than 13 seconds
The Speedtail’s petrol-electric hybrid powertrain delivers the greatest power and torque of any McLaren road car, with a combined 1,070 ps and 1,150 Nm. The straight-line acceleration and maximum speed of the car set new benchmarks for McLaren, with 0 – 300 km/h achieved in less than 13 seconds and a maximum speed reached of 403 km/h.

The McLaren-developed battery pack has a power density of 5.2 kW/kg, said to be the best power-to-weight ratio of any automotive high voltage battery system. The batteries constantly self-charge when the Speedtail is driven – there is no ‘plug-in’ element – however, a wireless charging pad that trickle-charges and maintains the battery’s status when the vehicle is not in use is also included as standard.

The first of 106 Speedtails that will be hand-assembled to customer order has now commenced at the McLaren Production Centre in the UK, with deliveries scheduled from February 2020. Each customer will pay more than US$2.25 million (equivalent to RM9.32 million today) which is the base price for the car before personalisation.

This is the 800hp McLaren Elva – no roof, windscreen or windows!

Ford Transit Smart Energy Concept extends EV range with innovative approaches, including ambient lighting

Ford Motor Company has revealed the new Transit Smart Energy Concept – a one-of-a-kind 10-seater minibus which is helping the automaker explore solutions for maximising the energy efficiency and driving range of electrified vehicles. However, the distance that drivers can travel on a single charge of a battery-electric vehicle (BEV) continues to be greatly impacted by the use of cabin heating features.

Research has showed that using the climate control system in a BEV can reduce the driving range by up to 50% in cold weather. Perhaps the same also applies in hot weather though there would be different issues creating the same drawback.

Challenges to energy usage
Compared to goods transport vehicles, multi-occupant vehicles such as minibuses require significantly more energy to create a comfortable temperature for occupants. The energy is provided by the high-voltage battery, presenting a significant challenge to the vehicle’s driving range. In vehicles with combustion engines, an engine-drive compressor is used as a separate pump for coolant.

Demonstrated recently, the fully-functioning, all-electric Transit Smart Energy Concept delivers 150 kms driving range from a 4-hour charge, supported by energy-saving and energy-generating innovations from solar panels to powertrain heat recovery systems.

“With frequent door openings, a large space to keep at comfortable temperatures, and a big payload to carry, a minibus presents the toughest challenge for maximising battery-electric vehicle range, and that’s exactly why we chose it for our new Transit Smart Energy Concept,” said Kilian Vas, Project Leader, Vehicle Architecture, Ford of Europe. “By developing this concept we’ve found a number of clever ways to save energy which could help further improve the electrified vehicle experience for customers in the future.”

Innovations that enhance energy efficiency
The Transit Smart Energy Concept uses the same drivetrain technology as the StreetScooter WORK XL commercial vehicle, and a Transit chassis fitted with a battery-electric drivetrain for zero-emissions driving. Innovations which enhance energy efficiency and driving range being tested for the first time include:

♦ An innovative heat pump system which utilises waste heat from the drivetrain components, the outside air, and the air within the cabin to reduce heating system energy usage by up to 65%, resulting in a range extension of 20%.;

♦ A power sliding door which opens halfway to reduce heat loss and can be activated by the passenger using a smart device. The heating, ventilation, and air-conditioning blower is automatically deactivated when the door is open;

♦ Heated business-class passenger seats and surfaces which enable passengers to control their local temperature, reducing the energy required for the large cabin;

♦ 6 roof-mounted solar panels which charge a 12V battery for powering seat heating, cabin lighting, and on-board electrical systems, including wireless charging for passenger mobile devices;

♦ A polycarbonate divider between the passenger door and seating area, which further reduces heat loss as passengers enter and exit, and protects passengers from external elements;

♦ Ventilated double-glazed windows which reduce cold contact surfaces, and insulate against heat loss; and

♦ An insulated rear floor and roof which further reduce cabin heat loss.

Colours can also help to go further!
Mood lighting which adjusts according to cabin temperature – red for warmth and blue for cooling – subliminally influencing passengers’ perception of cabin temperature. Experts claim colour choices can influence our mood, our responses… even how many likes we get on social media! Now Ford is exploring how matching the right colour to different driving situations could extend electric vehicle range.

The ambient lighting makes passengers feel warmer (with red lights) or cooler (with blue lights). This helps take the strain from the climate control system so that energy saved can instead be used to cover more kilometres.

In a trial simulating a winter’s day of 0° C and a summer’s day of 30° C, passengers were subjected to rate their level of comfort based on feeling too hot or too cold. In both cases, the ambient lighting resulted in reducing the power usage of the climate system: by 3.3% for cooling and 2.5% for heating.

“Our exposure to colour can change our mood in all sorts of ways. Here it is simply a case of using red ambient lighting inside the car to make people feel warmer and blue ambient lighting to make people feel cooler. Reducing the burden on the aircon could make a significant difference to extending vehicle range,” explained Lioba Muller, Lighting Team Engineer, Vehicle Architecture at Ford of Europe.

Visit www.sdacford.com.my to know more about Ford models available in Malaysia.

Your future Ford will have parts made from coffee bean skins!

Vision T concept may be a preview of the next Hyundai Tucson

In recent times, Hyundai has been using an evolving design language that maintained an overall familiarity. It’s referred to as ‘Sensuous Sportiness’ and has been applied globally. The design language is still evolving and is shown in the seventh model in a series of Hyundai Design Centre concepts – the Vision T Plug-in Hybrid SUV Concept.

The SUV concept, likely to be a preview of the next generation of the Tucson (the ‘T’ may be the clue), has a matte-green exterior finish and is powered by a plug-in hybrid powertrain indicating its eco-lifestyle focus and inherent balance with the environment in which it is driven.

2019 Hyundai Tucson 3rd generation — *Current Tucson which is in the third generation.*

Two derivative sub-themes
Two derivative sub-themes of the dynamism fundamental design concept are ‘Parametric Fantasy’ and ‘Transcendent Connectivity’. In these sub-themes, all parametric surfaces are connected from the body to either light or trim features. It features seamless connectivity free from distinct design boundaries.

Ambient light reflects off these concave and convex lines creating an extreme sense of tension. Charisma is added with the evolution of a Hidden Signature Lamp derived from the Le Fil Rouge and Grandeur Face Lift.

Parametric Air Shutter Grille Design
At higher speeds, the Parametric Air Shutter is an original developmental feature that actively adjusts both aerodynamics and design appearance. When stationary, the grille is closed and static. Once in motion, each individual cell of the grille design continues to move in a prescribed sequence, creating a truly dynamic forward stance. This dynamic character includes the functional effect of controlling airflow to the powertrain, optimizing aerodynamics and fuel efficiency.

The 4.6-metre long Vision T’s side profile conveys a continual sense of speed and forward motion. The long bonnet and level roofline coupled with a long wheelbase and short overhangs reflect a ready-for-anything dynamic character. In contrast to prevailing compact SUV designs, the Vision T uses crisp geometric angles and edges to create a striking contrast between a sleek silhouette and masculine wedge lines.

The side window design is ultra-clean and seamless, with a futuristic frameless daylight opening and a satin chrome garnish. The oversize satin chrome alloy wheels feature ample voided area with dark orange brake calipers visible within the split-5-spoke wheel design. The beveled sides of the wheel spokes feature a matte-gray finish descending into the voided areas, highlighting the brilliance of the satin chrome spoke faces.

From above, a special glass pattern is embossed within the roof glass structure. These dynamic effects carry into the Hyundai logo design. The H design is dark chrome; when illuminated it is enhanced with a bright green and deep red hue for sharper dimensionality.

Integrated Hidden Signature Headlamp
When the powertrain is started, the dark-chrome matte hue of the integrated hidden signature headlamp system features a half-mirror system that has a chromium appearance which transforms into functional lighting on demand. The designers have elevated the appeal of luminous parametric design through hidden DRLs, while the hidden signature lamp represents the next generation of this Hyundai design innovation.

The sequenced lighting theme carries through to the rear of the vehicle, demonstrated when the powertrain is shut down and the rear tail lamps and Hyundai logo follow a prescribed light extinguishing sequence, with the Hyundai logo as the last of the rear lighting signature to cease illumination.

The charging port for the battery pack is located on the passenger side rear quarter panel and features a sliding cover. When charging, ‘Blue Drive’ is illuminated, indicating the system is actively charging. The battery state of charge is also visually indicated externally in a metered, circular light cluster, creating a complete circle appearance when fully charged.

(more…)

FEATURE – When Mercedes-Benz also had a rotary-engined sportscar

Although most people only came to know about the rotary engine in the 1970s, Felix Wankel, who developed it, had received a patent in Germany as far back as 1929 and produced a working prototype at NSU (which would later become part of Audi) in 1957. The rotary engine was uniquely different from the reciprocating internal combustion engine and had besides its compactness and low weight, it also generated a high power output from a smaller displacement.

The engine was of great interest to many carmakers and at least 12 – including even Rolls-Royce – took licences to develop their own versions. However, apart from Mazda, which persevered to make it commercially viable and produced a number of models with rotary engines, the other companies eventually gave up work on it as they could not find solutions to its drawbacks.

Mazda Cosmo-Suzuki RE5 — *Mazda and Suzuki were two of the few companies that managed to commercialise the rotary engine in production models.*

Mercedes-Benz was interested
At Mercedes-Benz, the rotary engine certainly generated much interest. The company’s R&D department worked on it during the early 1960s, with a prototype SLX sportscar proposed using the engine. Even though the power and smoothness were attractions, fuel consumption and emissions were high and by 1976, Mercedes-Benz decided to end its rotary engine work.

*Mercedes-Benz rotary engines being produced for the C 111 in the early 1970s.*

However, during the development period, the company decided to use the rotary engine as a highlight of a futuristic super sportscar – the C 111. The designation had started off as ‘C 101’ but Peugeot was known to be very protective of its model numbering system which had a ‘0’ in the middle of the 3 digits (eg 304, 505, etc) and Mercedes-Benz decided to avoid any issues with the French carmaker by changing to ‘C-111’. In fact, it is believed that Peugeot had even approached Mazda to get it to change the designation of its 808 model in the 1970s but the request was probably not entertained.

Debut of the C 111
It was displayed at the 1969 Frankfurt Motor Show as an experimental vehicle with only 12 units produced. Wealthy customers imagined the C 111 to be a successor to the legendary 300 SL ‘Gullwing’ of 1954 and even sent blank cheques to factory to try to get one!

Mercedes-Benz C111 — *Debut of the C 111 at the Frankfurt Motor Show in 1969.*

The C 111 was a fascinating mid-engine sportscar which allowed the engineers to explore the performance of the rotary engine. The first one used in 1969 had a 3-rotor design with a chamber volume of 3 times 600 cc which could produce 280 bhp. After further development, the second version of the C 111 presented at the Geneva Motor Show in 1970 featured a 4-rotor engine with 4 times 600 cc and 350 bhp.

Running technology platform
Alongside the rotary engine, other technologies were tested in the C 111 like bodywork made of glass-fibre reinforced plastic and joining techniques such as adhesive bonding and riveting. This technological look into the future was underlined by the visionary design of the wedge-shaped super sportscar.

The iconic character of the C 111 was also reinforced by the unusual paint finish in metallic orange. The designation ‘Weissherbst’ derived from wine-making referred to the glowing orange/rosé colour of these popular wines. The vehicle displayed in Frankfurt was the first C 111 in this spectacular paint finish. The other vehicles in the first series, which were used as demonstration vehicles during the show, were still in a white paint finish, but were later likewise repainted in ‘Weissherbst’.

The rotary engine was not only visionary in concept but also delivered performance that was outstanding in its time. The first version of the C 111 reached a top speed of 260 km/h, and the second one even managed 300 km/h.

‘Second career’ as a record-breaker
In 1976, the C 111 appeared again as a record-breaking car with conventional reciprocating engines. Two versions with 5-cylinder turbodiesel engines were built, as well as the C 111-IV with a V8 petrol engine in 1979. On the high-speed track in Nardo, Italy, the C 111s established numerous new records, one of them the circuit world record with 403.978 km/h by the C 111-IV on May 5, 1979.

In 2014, the specialists at Mercedes-Benz Classic restored one of these dream sportscars from their collection to drivable condition. To preserve the few still available rotary engines for the future, they installed an M 116 3.5-litre V8 engine. This engine had already been installed in a C 111 for comparative and test purposes in 1970.

Click here for other news and articles about Mercedes-Benz.
